ADU Foundation Requirements: A Comprehensive Guide

Why the Right Foundation is Critical for Your ADU

Foundations are the stable base on which your entire additional dwelling unit will be built. In the short term, this means the foundation needs to be strong enough to support the weight of the entire structure you are building. In the long term, this means it needs to be structurally sound enough to ensure stability over decades.

This can be a particular challenge in California due to the state’s topography, soil composition, and seismic activity.

• Topography: Drive inland, and you’ll notice it doesn’t take long to go from flat beaches to steep hills and even mountain cliffs. This variance in topography and overall grading from property to property definitely plays a factor when choosing the right foundation for ADU construction.
• Soil composition: Like topography, the soil composition can vary widely, even among residential properties along the same street. Sandy soil, which is common in the state, drains well but can lead to settling if the proper foundation is not laid. Clay soil, which is also common, expands and contracts as it gets wet, which can lead to stability issues if not properly taken into consideration.
• Seismic activity: Of course, California is known for its earthquakes, and this always needs to factor into any construction project in the state, ADU or otherwise. This keeps families — and their homes — safe.

Foundations affect long-term stability and adaptability. Plan for future solar panels or utility expansions to get the most value out of your investment.

What Type of Foundation Does an ADU Need?

There’s no one kind of foundation that supports all ADU construction. The factors we just touched on above — topography, soil composition, and seismic activity — and others all come into play when choosing which type or style of foundation to use.

While your contractor will suggest the foundation they believe is best after careful assessment, it’s important to familiarize yourself with the most common types of ADU foundations so you can ask questions and be an informed participant in the construction process.

Slab-On-Grade Foundations

Slab-on-grade foundations are the most common foundations with ADU builds. They’re concrete slab foundations built on grade (leveled ground). Along with serving as the structure’s foundation, foundation slabs also double as the subfloor for the first level.

Foundation slabs are poured all at once, though some preparation may need to be done to ensure the ground is level. If the ground cannot be made level for some reason, either due to unstable soil conditions or the grading of your yard, your contractor should suggest another type of foundation, like the ones below, to ensure structural integrity.

Slab-on-grade foundations are cost-efficient for level sites. Adding vapor barriers beneath improves moisture resistance, critical in damp or humid climates.

Raised Foundations

If your yard cannot be leveled to accommodate a slab-on-grade foundation or you live in an area prone to flooding, your contractor may suggest a raised foundation for your ADU.

With a raised foundation, large, load-bearing footings are placed in the ground, going down anywhere between 18 and 24 inches and extending up beyond the ground’s surface. On top of these footings, slightly above ground level, a wooden foundational pad will be built. This wooden pad will also serve as the subfloor for the first level.

Raised foundations involve more planning and materials than a slab-on-grade foundation but can ultimately be worth it and allow ADUs, granny flats, and carriage houses to be built even on more challenging sites.

Stem walls provide stability on sloped terrain, doubling as a barrier against erosion. They also allow space for crawl areas or added insulation.

Stem Wall Foundations

Raised foundations are often used when the ground slopes downward and cannot be leveled. But if you live at the base of a hill instead of the top, the ground may slope upward and cannot be leveled.

In these cases, a stem wall foundation may be used. A stem wall foundation is a concrete slab with a small concrete wall that extends upward against the area where the grade is highest. Think of it a bit like a retaining wall attached to the foundation.

These provide the ease of a concrete foundation while still ensuring stability against uneven ground.

Raised foundations prevent flooding damage and work well on uneven land. Reinforced footings improve resilience in areas with heavy rainfall or poor soil.

Hybrid Foundations

To safely build an ADU on the most challenging sites, a hybrid foundation might be used.

Hybrid foundations vary greatly from project to project but generally involve a variety of foundation types. For example, a stem wall may be implemented on the back of the foundation, while a raised foundation may be used on the front. Hybrid foundations can also employ a variety of footings, with deeper ones used in certain locations and more standard-sized footings used elsewhere. Given the design complexity of hybrid foundations, they can add to the overall construction budget and construction time.

View this post on Instagram

A post shared by Better Place Design & Build | San Diego ADU Builders (@betterplaceadu)

What are the Minimum Requirements for Building an ADU Foundation in California?

The state of California is invested in the building of ADUs. They see ADUs as a way to combat the housing crisis and increase the number of affordable housing options available to low-income families. Given this investment, the state has passed some broad requirements pertaining to the building of ADUs but has given municipalities some leeway when it comes to deciding the exact requirements for ADUs in their area.

This means that the architectural design, zoning, permitting, and inspection process for your ADU can vary depending on your city and whether you are building an attached or detached unit.

A few minimum requirements you can expect on most projects, though, include:

• A soil analysis. A soil analysis is required before beginning any ADU construction. It is the most accurate way to determine the exact composition of the soil in your yard so you can design and build a strong foundation that will resist flooding and settling.
• A 12-inch foundational depth. This is the bare minimum depth for concrete slab foundations, though depending on the square footage of your ADU, the soil composition and overall grading of your yard, and the seismic activity for your area, this may need to be deeper, especially when it comes to footings.
• Rebar reinforcements. For slab-on-grade foundations, rebar reinforcements are required. What those reinforcements look like for your exact foundation depends on the results of the soil analysis, with certain soil types requiring more reinforcement.
• Vapor barrier. Concrete-based foundations often require a vapor barrier to be installed underneath the slab to prevent moisture from getting into the home and eroding the foundational integrity over time.

California’s seismic codes require reinforced foundations. Ensure soil testing, footings, and vapor barriers meet local standards to pass inspections smoothly.

How Much Does It Cost to Build an ADU Foundation?

The cost it takes to build a strong foundation for your accessory unit varies depending on the materials used and the type of foundation being built.

If your yard is level and can support a concrete slab foundation that can be poured in one day, the budget for the foundation phase will be less than a project that requires a hybrid foundation with heavy excavation and overall site prep. Local labor rates also come into play here. If labor rates in your area are high and your foundation design is more complex, this can inflate your foundation costs.

If you are curious about whether a secondary dwelling unit is within your budget, we have a cost calculator that allows you to see what your ADU construction costs may be based on your exact property and build. You can also reach out for a free estimate at any time.

If you are like many of our clients who choose to embark on an ADU construction journey, though, you will find it’s worth the investment. ADUs provide families with the immediate potential for rental income while also increasing the overall value of their property.

Foundation costs vary with site conditions and materials, but investing in quality ensures long-term savings by reducing repair risks caused by shifting soil.

The Foundation Construction Process: From Start to Finish

The foundation phase is not only one of the most crucial construction phases; it is also the first. Here is what you can expect from the process once you have submitted your permit application request and have ultimately had your building permit application approved.

Site Assessment and Soil Testing

Choosing the correct foundation type is crucial. This decision is ultimately the result of two things: a site assessment to assess the grade and topography of your property and a soil test to see what kind of soil — sand, clay, loam, etc. — you are building on top of. The results of these tests will ultimately help your team make important decisions about construction methods for your foundation.

Soil testing is critical for designing a stable foundation, identifying risks like settling or poor drainage early to avoid costly repairs down the line.

Excavation and Preparation

Before a solid foundation can be poured, the site must be prepped. This looks different from project to project.

For ADUs being built on already level ground, the preparation usually involves a simple excavation of the area where your ADU will ultimately sit. For ADUs being built on uneven ground, more work may need to be done as crews dig out additional earth or fill it in to achieve the ideal grade for your foundation.

This part of the process also includes any demolition of existing structures, removal of trees, digging of sewer trenches, and/or preparation for underground utilities and utility connections, if needed.

Proper excavation sets the stage for a solid foundation and prevents future issues like settling or drainage problems. Ensure utility lines are identified and protected.

Laying the Foundation

With the site properly prepped, the construction crew is ready to lay the foundation. Depending on the type of foundation being used, this could be as simple as pouring a concrete foundation pad, or it may involve a mixture of concrete, wood, and lots of reinforcing.

Finding a contractor you feel comfortable talking to is important, as they can walk you through what this phase of the project will look like for your exact build. Your contractor can also submit an inspection request once the foundation work is complete and help schedule inspection so you can move on to the next phase of your build.

View this post on Instagram

A post shared by Better Place Design & Build | San Diego ADU Builders (@betterplaceadu)

Common Challenges When Building ADU Foundations

Poor soil quality and drainage issues are common problems we see when building a strong foundation for an ADU project. Oftentimes, these factors are ultimately what dictate the type of foundation we employ, with the most complicated projects requiring some form of hybrid foundation.

An experienced contractor is the best person to identify challenges and suggest a workaround that will not only keep the project on budget but also help it to pass building inspection and maintain structural integrity for years to come.

For examples of some of our most recent projects, all of which came with their own challenges, foundational or otherwise, check out our projects page.

The Importance of a Structural Warranty for Your ADU Foundation

Ensuring your ADU construction includes some kind of structural warranty for the foundation is critical. Any foundation is prone to issues such as settling or cracking over time, but if the foundation was not built properly, these issues can be severe, jeopardizing the functionality and safety of your ADU in a short period of time.

When signing an agreement with your contractor, be sure to look into the warranties they include as they pertain to defects related to materials, workmanship, or compliance with the local building codes. Generally, the structural warranties offered by most ADU builders range between 5 and 10 years, depending on the builder and location. If the warranty is much less than this, we caution you to be wary.

At Better Place Design & Build, our commitment to quality is not only apparent in our healthy structural warranty but also in our professional demeanor and clear, open style of communication.

What is the Best Foundation for an ADU?

After reading this post, we hope two things are apparent: 1) there is no one best style of foundation for an ADU; it varies from project to project, and 2) the best person to decide which foundation type is right for your ADU is an experienced builder in both ADUs and residential construction, like Better Place Design & Build.

The best foundation balances site conditions, budget, and future needs. Discuss reinforcements with your contractor to accommodate future upgrades.
